35
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
AHD
SEC
Lock a Wall Panel (AHD) into the right front corner position by inserting the tabs at the bottom of the Wall Panel
into the slots on the Shed Floor. After inserting the tabs, slide the Wall Panel to the right to lock it in place.
Install a Window Wall Panel (AHH) and secure with six (6) 1/4” x 5/8” Phillips Pan-Head Screws (ADZ).
WALL ASSEMBLY
SEC
Install two more Wall Panels (AHD)BOETFDVSFXJUIUXFMWF1/4” x 5/8” Phillips Pan-Head Screws (ADZ).
ADZ (x18)
AHH
AHD
AHD
Note: A second adult should apply pressure to the opposite side of the wall for easy insertion of screws.
!
4
4.1
4.2
