Lifetime 6417 - Wall Panel Installation

34
4
Safety Glasses
WALL PANEL INSTALLATION
HARDWARE REQUIRED
HARDWARE BAG REQUIRED: BMX
HARDWARE BAG REQUIRED: BMX
METAL PARTS REQUIRED
PLASTIC PARTS REQUIRED
TOOLS REQUIRED
SEC
AHD (x10)
Wall Panel
Part shown at 8% of actual size
Hardware shown at actual size
Part shown at 4% of actual size
AHHY
Window Wall Panel
AFRY
Corner Channel
77 1/2”
ADZ (x78)
1/4” x 5/8” Pan-Head Screw
Phillips Screwdriver
ADC (x1)
1IJMMJQT#JU
ADC (x1)
1IJMMJQT#JU*ODMVEFE
METAL PARTS KIT REQUIRED: BNN
LOCATED IN BOXES: 2, 3, 4
