Lifetime 6417 - Page 49

49
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
7.1
7.1
SEC
SEC
Insert an End Plug (BBH) into each end of the Extended Door Brace (BLG), as shown.
4FDVSFUXPDoor Braces (AFB) and the Extended Door Brace (BLG) to the inside of the Center Door (AGZ), as shown,
using the required hardware.
ADZ (x9)
AFB
AFB
BLG
AGZ
CENTER DOOR ASSEMBLY
BBH
BBH
ADZ
ADZ
ADZ
ADZ
ADZ
ADZ
ADZ
ADZ
ADZ
BLG
BBHY
8
8.1
8.2
