Lifetime 6417 - Door Frame and Door Installation

58
DOOR FRAME AND DOOR INSTALLATION
HARDWARE REQUIRED
METAL PARTS REQUIRED
SEC
ADZY
1/4” x 5/8” Pan-Head Screw
BBN (x1)
Carriage Latch
BLJY
Corner Door Frame
Parts shown at 8% of actual size
Hardware shown at actual size
1BSUTIPXOBUPGBDUVBMTJ[F Parts shown at 50% of actual size
BMG (x1)
Right Hinge Assembly
AHLY
Dead Bolt Strike Plate
BBJ (x1)
4” Floor Strike Plate
BBEY
Carriage Wheel
BBG (x1)
wYw)FY#PMU
AAVY
5/16” Jam Nut
BBK (x1)
Carriage Bracket
BBL (x6)
wYw)FY#PMU
BBM (x4)
wYw5ISFBE$VUUJOH4DSFX
10
78 1/4”
Top
Bottom
78 1/4”
ABU (x6)
wYw$BSSJBHF#PMU
AEB (x8)
1/4” Flat Washer
CJRY
Door Frame Support Bracket
ACA (x4)
wYw$BSSJBHF#PMU
ADJ (x16)
1/4” Cap Nut
HARDWARE BAG REQUIRED: BNE
LOCATED IN BOX 4 AND METAL PARTS KIT: BNM
AID (x1)
L-Key with Phillips Head
