Lifetime 6417 - Page 76

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
76
SEC
11
11.4
11.5
REAR CORNER TRIM INSTALLATION
11.1
11.1
11.2
SEC
11.4
SEC
11.5
Snap six (6) Plastic Corner Trim Brackets (AGA)UPBSFBSDPSOFSPGUIF4IFE'BTUFOFBDI#SBDLFUXJUIUXP#10 x
1/2” Phillips Pan-Head Screws (ADX).
Slide a Corner Trim (AQX) onto the Plastic Corner Trim Brackets.
Align the top of the Corner Trim with the top of the Wall Panel and
fasten with a #8 Phillips Pan-Head Screw (ACK). Insert the Screw on
the side of the Shed to hide it under the eaves. Repeat steps 11.4 -
11.5 for the second Rear Corner Trim.
AGA
ADX
ADX
AQX
AQX
ACK
ADXY
ACKY
Note: The tab on the Trim Brackets fit into the six screw indentations along each corner of the Shed.
!
WARNING
Use extreme caution when standing on ladders to
perform assembly steps. Follow all warnings and
cautions on the ladder. Failure to follow all of these
instructions and warnings could lead to serious
personal injury or property damage.
