Lifetime 6417 - Page 77

77
ADK
$BQ/VU
AEE
Yw'MBU8BTIFS
ACRY
Yw$BSSJBHF#PMU
AHBY
Roof Panel for Domed Skylight
AGBY
Domed Skylight
*AHIY
Butyl Tape
Phillips Screwdriver
3/8” Wrench
Safety Glasses
DOMED SKYLIGHT ASSEMBLY
HARDWARE REQUIRED
HARDWARE BAG REQUIRED: BEC
PLASTIC PARTS REQUIRED
TOOLS REQUIRED
SEC
Part shown at 4% of actual size
Part shown at 8% of actual size
Hardware shown at actual size (*Unless noted otherwise)
12
LOCATED IN BOXES: 2, 3
