Parts List
Box 1
ID Reorder# Part# Description Qty
Main Hardware
109 1020143 109 Outer Floor Panel 2
111 1034880 111 Front Gable 1
112 1036552 112 Lt Rear Gable 1
113 1036553 113 Rt Rear Gable 1
114 1009262 114 Roof Panel 4
115 CB11580C 115 Front Roof Cap 1
116 CB11680C 116 Rear Roof Cap 1
117 CB11780C 117 Center Roof Cap 1
118 1033359 118 Lt Shed Door 1
119 1033360 1008663 Rt Shed Door 1
AB 1021644 Roof Truss Brace 1
AC 1021645 Roof Truss Channels 2
AD 1023425 Rear Wall Support 1
AE 1021483 Door End Channel 2
AF 1021626 Gable Support Sq Tube 1
AH 1009232 Skylight 2
Vent Hardware Bag [HH11900] x2
VA CH08381 Louvered Vent 1
VB DA03700 Vent Screen 1
PB BS05800 #10 x. 75” Pan-hd Screw 6
VC BW01300 #10 Washer 6
Box 2
ID Reorder# Part# Description Qty
104 ZS10482 104 Rt Front Corner Panel 1
105 1033375 105 Lt Front Corner Panel 1
106 1033376 106 Rt Back Corner Panel 1
107 1033377 107 Lt Back Corner Panel 1
108 ZS10882 108 Wall Panel 4
AG 1021649 Roof Support 4
Shed Parts Box [1033431]
ID Reorder # Description Qty
Main Hardware
BD IA01400 Wood Block 1
BE IA01500 Wood Shim 4
Door Handle Parts Bag [1033418]
BB 1015792 Right Door handle 1
BC 1009123 Left Door Handle 1
Thumb Lever Hardware Bag [1033072]
HD BG01600 Door Spring 1
HG 1015832 Thumb Lever 1
PB BS05800 #10 x .75” Pan-Head Screw 1
XX 1023505 Latch Block 1
ID Reorder# Description Qty
Truss Support Hardware Bag [1001882]
HL BN00300 1/4” Cap Nut 2
SA BB04500 Threaded Rod 1
Skylight Hardware Bag [1000315]
LA BS05900 #10 x .5” Pan-Head Screw 13
LB BW01200 #10 Fender Washer 13
Door Handle Hardware Bag [1033168]
HA AC00100 Latch 1
HB 1000118 1/4” x 2” Carriage Bolt 2
HC 1000109 1/4” x 1.25” Carriage Bolt 2
PB BS05800 #10 x .75” Pan-Head Screw 7
VC BW01300 #10 Washer 6
HH BA05700 .375” x .56” Steel Spacer 2
HI 1021484 Latch Cover Plate 1
HL BN00300 1/4” Cap Nut 2
HM 1020983 Deadbolt Latch 2
HR 300022 1/4” Center Lock Nut 2
HS 1021406 Right Door Latch 1
HT 1021405 Left Door Latch 1
HU 1014524 Bushing, Door Hinge 2
HV 1015692 Cotter Pin 2
HW 1014394 Strike Plate 1
HX BW00300 1/4” Flat Washer 2
Front Gable Hardware Bag [1020803]
GA BS05700 .25” x 1.125” Pan-hd Screw 14
GB CF03399 End Plug 4
GC 1005981 #10 x 1.5” Pan-hd Screw 1
Truss Hardware Bag [1021658]
TA 1021654 Truss Connector 1
HK BN01600 #10 Cap Nut 7
TC BS06100 #10 x 3/8” Pan-Head Screw 7
TD DA04000 L-Key w/Phillips Head 1
TE BA07000 #2 Phillips Bit 1
TF CH14082 Gable Clip 2
Shed Screw Hardware Bag [1001634]
SS BS07500 1/2” Phillips Head Screw 163
Door Gap Flap Hardware Bag [1004034]
FA CH14199 Left Gap Flap 1
FB CH14499 Right Gap Flap 1
LA BS05900 #10 x .5” Pan-head Screw 4
*Part Numbers are listed when different from the Reorder Number.
The Part Number will appear on most of the plastic parts.
Two Adults Required for Assembly
( + one Adult suggested as an instruction reader)
Before Beginning Assembly
Remove this Parts List and Hardware Identifi er
from the Instructions and take an inventory of all
parts in both boxes.
