Lifetime 6426 - TRUSS ASSEMBLY; Truss Assembly Requirements

18
20 1/8”
71 11/16”
79 1/2”
79 1/2”
7/16” WrenchX
TRUSS ASSEMBLY
HARDWARE REQUIRED
HARDWARE BAG REQUIRED: BGV (x2)
METAL PARTS REQUIRED
TOOLS REQUIRED
SEC
Safety Glasses
AFP (x4)
Truss Support Strip
AIPX
4RUSS'UTTER#ONNECTOR
AHT (x4)
Floor Bracket
AFH (x4)
4RUSS'UTTER#HANNEL
AFGX
Truss Brace Channel
AFQ (x4)
Wall/Shelf Support Channel
AAKX
vXv(EX"OLT
ADJX
1/4” Cap Nut
Parts shown at 8% of actual size
Hardware shown at actual size
Hardware shown at 50% of actual size
4
