Lifetime 6426 - WINDOW ASSEMBLY & INSTALLATION; Window Assembly Requirements

22
Phillips Screwdriver
WINDOW ASSEMBLY & INSTALLATION
HARDWARE REQUIRED
PLASTIC PARTS REQUIRED
TOOLS REQUIRED
SEC
Safety Glasses
Hardware shown at actual size
Parts shown at 8% of actual size
ADZ (x8)
1/4” x 5/8” Pan-Head Screw
AEE (x4)
Xv&LAT7ASHER
ACF (x4)
Xv0AN(EAD3CREW
ACB (x8)
Xv0AN(EAD3CREW
AIE (x4)
Mounted Window Stay
AIU (x8)
Window Latch Bearing
AHG (x4)
Window Frame
AHF (x4)
Window
AIN (x4)
Sliding Window Stay
AIT (x8)
Window Latch
AIV (x4)
Window Stay Bracket
AIR (x8)
Window Hinge Tube
ADW (x8)
Xv0AN(EAD3CREW
ADX (x44)
Xv0AN(EAD3CREW
(ARDWARESHOWNATOFACTUALSIZE
Hardware shown at 50% of actual size
ACD (x4)
Xv&LAT(EAD3CREW
ADK (x4)
#AP.UT
1004595
HARDWARE BAG REQUIRED: BGU (x2)
