Lifetime 6426 - WALL & ROOF INSTALLATION; Wall & Roof Installation Requirements

28
WALL & ROOF INSTALLATION
HARDWARE REQUIRED
METAL PARTS REQUIRED
PLASTIC PARTS REQUIRED
TOOLS REQUIRED
SEC
6
Phillips Screwdriver
7/16” WrenchX
Safety Glasses
Parts shown at 4% of actual size
1000272
100XXXX
AHHX Window Wall Panel Assembly (Assembled in Section 4)
AHDX Wall Panel
Hardware shown at actual size (*unless otherwise indicated)
ADZX
1/4” x 5/8” Phillips Pan-Head Screw
ACJ (x8)
Xv0HILLIPS0AN(EAD3CREW
AED (x8)
Xv&ENDER7ASHER
AJA (x8)*
Foam Cube
1021070
Part shown at 8% of actual size
Part shown at 8% of actual size
1000476
28 7/8”
AFYX
Center Roof Cap
AFLX
Roof Support Strip
AGQ (x4)
Center Roof Panel
HARDWARE BAG REQUIRED: BGT
