Lifetime 71281 - SEC 4.2 Connect Long Extension Arms; Connecting Long Extension Arms

36
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
4.2
7 1/16”
4MJEFUIF1/2” x 7 1/8” Hex Bolt (AAD)UISPVHIUIF LongExtension Arms (AKB)
9/16” x .592” Spacers (ABL) BOEBackboard Brackets (AJK&AJJ)BTTIPXO5IFO
TFDVSFUIFNXJUI1/2” Centerlock Nut (ABL)5JHIUFOUIF/VUVOUJMJUJTnVTI
XJUIUIF#PMU
AKB
AKB
AAX
ABL
ABL
AAD
X
X

1/2”

AADY
AAX Y
ABLY
