4
1179628
10/24/2016
4
I
CON LEGEND
Indicates special heed should be taken when reading.
Indicates the parts to be used for a section.
Indicates no parts required for a specifi c section.
Indicates the hardware to be used for a section.
Indicates no hardware required for a specifi c page.
Indicates the tools to be used for a section.
Indicates to use/not to use an electric drill for a specifi c step.
Indicates the use of a centerlock nut. A nut with this marking will require some effort to tighten. This
hardware was designed with this feature in order to prevent loosening later.
A cordless drill can be used for driving screws;
however, care should be taken not to over-tighten or strip screws.
USE AT YOUR OWN RISK!
USING A DRILL IS NOT RECOMMENDED FOR DRIVING BOLTS.
!
