Lifetime 90135 - Section 1: Base Assembly

13
Metal Part
Hardware Bag
TOOLS REQUIRED
PARTS REQUIRED
HARDWARE REQUIRED
B
ASE ASSEMBLY
1
CQY
CVZ (x17)
ASE (x1) ATE (x4)
ASN (x2)
DXY (x14)
ATB (x14)
ARN (x1)
ARU (x1)
ATD (x2)
ATC (x2)
CPN (x1)
CPL (x1) CPM (x1)
CPP (x2)
CPQ (x2)
CPO (x1)
CPR (x2)
3/4 in/po (≈19 mm)
(2)
1/2 in/po (≈13 mm)
(1)
!
• Part CPU is packaged inside part CPQ. Part CPV is packaged inside part CPP. Please remove these parts
before assembly.
3/16 in/po (≈5 mm)
(2)
