27
Metal Part
Hardware Bag
TOOLS
REQUIRED
P
ARTS REQUIRED
H
ARDWARE REQUIRED
WING ASS
EMBLY
3
CRA
ASB (x2)
CVZ (x20)
ATB (x18)
DXX (x18)
CQD (x4)
CQC (x2)
CQE (x2)
CQF (x2)
CQG (x1)
3/16 in/po (≈5 mm)
(2)
