Lifetime 90135 - Step 2.13: Attach Chain Foot Rest

26
TOOLS AND HARDWARE REQUIRED
X SECTION 2 (CONTINUED)
2.13
CVZ
ATB
CVZ
DXX
DXX
ATB
CQL
• Secure the Chain Foot Rest (CQL) to the Fuselage with the hardware shown by positioning the chain links over the holes
in the fuselage.
DXX (x2)
ATB (x2)
CVZ (x2)
3/16 in/po (≈5 mm)
(2)
