PARTS IDENTIFIER / IDENTIFICATEUR DE PIÈCES / IDENTIFICADOR DE PIEZAS
Metal Parts / Pièces en métal / Piezas de metal
Remove This Section / Enlevez cette section / Reitire esta sección
ALI (x2)
AJJ (x1)
AJK (x1)
ALX (x1)
• Warning Sticker applied to side not shown
• L’Autocollant d’avertissement apliqué au côté n’est pas illustré
• Etiqueta de advertencia aplicada al lado no está ilustrado
26” (660mm)
AKB (x2)
7” (178mm)
AJE (x1)
15 3/4 ” (400mm)
AJC (x1)
v
ALB (x1)
AKQ (x1)
AKC (x2)
17
17’’ (430mm)
AJY (x1)
ALL (x1)
AJI (x1)
* The Axle (AJE) is located in the parts bag, possibly within the Spring (AJY).
L’essieu (AJE) est situé dans le sac des pièces, peut-être dans le ressort (AJY).
El eje (AJE) se encuentra en la bolsa de partes, posiblemente en el muelle (AJY).
ALH (x1)
ALF (x1)
ALE (x1)
30 1/2 ” (77,5 cm)
” (109 cm) 34
” (109 cm) 34
