LEGO SINGAPORE 21057 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 23
Legend
DISCONNECT
CONNECT /
RECONNECT
TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
15cm Connecting Cable
6-Port Expansion Board
Connect the other
end to a 5V USB
Power Bank, 5V USB
Wall Adaptor, or USB
to AA Battery Pack
(sold separately)
Grab the right
4 cables from the
Supertrees and twist
them together
Grab the
remaining 2 cables
from the Supertrees
and twist them
together before
connecting them into
the 6-Port Expansion
Board containing
two 15cm Connecting
Cables
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.
Connect the 15cm
Connecting Cable
from the 6-Port
Expansion Board
into the Micro 8-Port
Expansion Board
from Step 8
