Technical Specifications:
·LED: 9 x 12W 6in1 (RGBAW+UV)
·Beam angle: 25 degree
·Power consumption: 100W
·Voltage: AC110V-250V. 60Hz-50Hz
·Built-in scenes&sound active
·DMX control: 1ch,2ch,3ch,4ch,5ch ,6ch ,7ch.,8ch,9ch for optional
·Master and slave control
·Weight: 2.5Kgs
·Size: 280*250*350mm
Operation Instructions (LCD DISPLAY) :
On LED Display, please NOTE:
When the digit flash, that means you can select this mode and via UP/DOWN to
choose. The display shut off after 30 seconds and when press again, it will light up.
Setting the DMX address:
DMX MODE
ADDR:001
Setting DMX Mode:
CHANNEL
CH:01
Via UP/DOWN to select 5channel or 3channel mode:
Setting Dimmer curves:
Dimmer Curve:
Linear/.Suqare
Linear: dimmer curve linear
Square: dimmer curve Square
