Setting Master / Slave mode:
When the display shows:
S L A V E
M O D E
It is the slave setting and will run after the master unit.
DMX Protocol:
Press MODE button until the display shows Addr, you can now set the desired
address via UP / DOWN buttons.
The device has 9 DMX modes as following:
1 channel mode:
Channel:
Value:
Function:
1
000-255
R+G+B+W+A+UV (0-
100%)
2 channel mode:
Channel:
Value:
Function:
1
000-255
R+G+B+W+A+UV (0-
100%)
2
000-255
Strobe (0-100%)
3 channel mode:
Channel:
Value:
Function:
1
000-255
Red (0-100%)
2
000-255
Green (0-100%)
3
000-255
Blue (0-100%)
4 channel mode:
Channel:
Value:
Function:
1
000-255
Red (0-100%)
2
000-255
Green (0-100%)
3
000-255
Blue (0-100%)
4
000-255
White (0-100%)
