LightmaXX Shaft 5R Beam Moving Head ______
4.2 Device power
The connecting operator must have the relative certificate. Confirm that power voltage accords to the power
marked on the lamp. Make sure, it has overload and leakage protection.
Caution: Connect the equipment to the power supply directly .Do not connect to the silicon box color system,
otherwise it will damage the device. The device has to be equipped with a standard 3-pin plug and socket, the
line yellow / green can be connected to ground .If you still have any questions, consult a qualified electrician.
4.3 Connectivity standard
The Connection to the grid occurs via PowerCon power cable.
Other connection options have to be executed by a qualified electrician.
For connection to any DMX Light Controllers, please use the specified XLR 3 Pole connections IN & OUT. (Pic 5)
The DMX Connection between the devices has to occur with matching DMX XLR 3 Pole cables.
To prevent any controlling fails, please always use DMX terminator plugs at the end of the DMX line.
The maximum numbers of devices you can operate in one DMX line are thirty.
If you operate a high number of devices, please always use DMX splitter for safety reasons.
Caution！Do not overload the connection, serial connection up to 30 devices can be accessed using 17-
channel mode. Specific details refer to the DMX512 protocol.
4.4 Light bulbs instructions and installation
1. Light bulbs instructions
Philips MSD Platinum 5R
OSRAM SIRIUS HRI 190W VSE 60
Caution！Installing other similar types of bulbs may cause potential safety hazard and equipment damage .In
order to reduce the risk of lamp damage, change the bulb before the light bulb exceed 100% service life span.
20
