Lightmaxx VECTOR BSW 10R MKII User Manual

DEUTSCHENGLISHFRANCAISESPAÑOL
24
DEUTSCHENGLISH
Model VECTOR BSW 10R
Lamp Osram SIRIUS HRI 280 Watt
Channel mode 16/24 DMX512 channel
Pan scan 540° (16 Bit) electric correction
Tilt scan 270° (16 Bit) electric correction
Motor 2-phase engines
Color wheel 13 colors
Gobos Gobo wheel 1: 13 static Gobos + open
Gobo wheel 2: 9 rotating Gobos Ø= 14,7mm + open
Effect wheel 1 rotating eight face prism (circular)
1 rotating six face prism (linear)
Dimmer mechanical, 0-100%
Strobe Macro
Lense morised zoom 3.8°-20° & lienear focus
Power input 100-240V, 50/60Hz
Power dissipation 420 Watt
Protection system Over heat protection, IP20 classified
Power supply AC/DC, magnetic ballast
Maße 523 x 337 x 570mm
Gewicht 20 Kg

Lightmaxx VECTOR BSW 10R MKII Specifications

General

Brand	Lightmaxx
Model	VECTOR BSW 10R MKII
Category	DJ Equipment
Language	English
