Lightmaxx Vector BSW 10R - Page 10

10
24 16 Value Name Description
CH1 CH1 000-255 X Pan Movement by 540°
CH2 000-255 X-fine Fine Pan
CH3 CH2 000-255 Y Tilt Movement by 540°
CH4 000-255 Y-fine Fine Tilt
CH5 CH3 000-255 XY Speed Speed from max. to min. (vector mode)
CH6 CH4
000-129
Power Macro
Empty
130-139 Lamp On, reset (total reset except pan/tilt reset)
140-149 Pan/Tilt reset
150-189 Effect motor reset
200-209 Total reset
210-229 Empty
230-239 Lamp Off
240-255 Empty
CH7 Ch5
000-008
Colour
Open/white (100% - 10%)
009-017 Colour 1 (100% - 10%)
018-026 Colour 2 (100% - 10%)
027-036 Colour 3 (100% - 10%)
037-045 Colour 4 (100% - 10%)
046-054 Colour 5 (100% - 10%)
055-063 Colour 6 (100% - 10%)
064-072 Colour 7 (100% - 10%)
073-081 Colour 8 (100% - 10%)
082-090 Colour 9 (100% - 10%)
091-100 Colour 10 (100% - 10%)
101-109 Colour 11 (100% - 10%)
110-118 Colour 12 (100% - 10%)
119-127 Colour 13 (100% - 10%)
128-129 Open/white
130-134 Colour 1
135-138 Colour 2
139-143 Colour 3
144-147 Colour 4
148-152 Colour 5
153-157 Colour 6
158-161 Colour 7
162-166 Colour 8
DMX Definition Table
