24 16 Value Name Description
CH14 CH10
224-231
Prism
Macro 13
232-239 Macro 14
240-247 Macro 15
248-255 Macro 16
CH15 CH11 Prism rotation
Circular rotating prism -indexing
000-255 0-200°
Circular rotating prism -rotation
000 No rotation
001-127 Forwards Prism rotation from fast to slow
128-129 No rotation
130-255
Backwards Prism rotation from slow to fast
CH16 CH12
000-127
Frost
Open/hole
128-255 Frost
CH17 CH13 000-255 Zoom Zoom from max. to min. beam angle
CH18 000-255 Zoom fine Fine Zoom
CH19 CH14 000-255 Focus Continuous adjustment from far to near
CH20 000-255 Focus fine Fine Focus
CH21 N/A
CH22 CH15
000-031
Shutter
Shutter closed
032-063 Shutter open
064-095 Strobe effect from slow to fast
096-127 Open
128-159 Opnening pulse in sequences from slow to fast
160-191 Open
192-223 Random strobe effect from slow to fast
224-255 Open
CH23 CH16 000-255 Dimmer 0-100% dimmer
CH24 N/A
DMX Address 001-512
Run Mode
DMX 16 channel
DMX 24 channel
Auto Run
Sound Control
Master/Slave Mode
Light switch sure
no
Channel Qty. simple
expand
