Lightmaxx Vector BSW 10R - Page 13

13
24 16 Value Name Description
CH11 CH8
146-153
Rotation/Shaking
Rotation Shaking Gobo 3 from slow to fast
154-161 Rotation Shaking Gobo 4 from slow to fast
162-169 Rotation Shaking Gobo 5 from slow to fast
170-177 Rotation Shaking Gobo 6 from slow to fast
178-185 Rotation Shaking Gobo 7 from slow to fast
186-193 Rotation Shaking Gobo 8 from slow to fast
194-199 Rotation Shaking Gobo 9 from slow to fast
200-201 Open/hole
202-221 Frowards Gobo wheel rotation from fast to slow
222-223 Open/hole
224
Forwards
225-243 Backwards Gobo wheel rotation from slow to fast
244-255 Auto random Gobo selection form fast to slow
CH12 CH9 Gobo rotation
Rotation pattern channel set to index location
000-255 0-200°
When the rotation pattern is set to the stream channel
000 no rotation
001-127 Forwards Gobo wheel rotation from fast to slow
128-129 no rotation
130-255 Backwards Gobo wheel rotation from slow to fast
CH13 no rotation
CH14 CH10
000-019
Prism
Open position (hole)
020-049 6-face linear rotating prism -indexing
050-075 6-face linear rotating prism -rotation
076-105 8-face circular rotating prism -indexing
106-127 8-face circular rotating prism -rotation
128-135 Macro 1
136-143 Macro 2
144-151 Macro 3
152-159 Macro 4
160-167 Macro 5
168-175 Macro 6
176-183 Macro 7
184-191 Macro 8
192-199 Macro 9
200-207 Macro 10
208-215 Macro 11
216-223 Macro 12
