CH5 Prism
load
DMX value: Effects: Attribute:
128-255 ON Single step
0-127 OFF Single step
DMX value: Effects: Attribute:
CH6 Prism rotation
193-255 Clockwise rotation / slow -> fast Linearity
191-192 Stop Single step
128-190 Anticlockw. rotation / fast -> slow Linearity
0-127 0° -> 540° Linearity
CH7 0-255 No function
CH8 Atomization
frost effect
0-255 Atomization / white -> full Linearity
CH9 ZOOM 0-255 ZOOM / near -> far Linearity
Explanation: CH10 each unit adjust angle 2.12°
CH10 X axle PAN
movement
0-255 X axle movement / 0° -> 540° Linearity
Explanation: CH11 each unit adjust angle 0.008°
CH11 X axle PAN
fi ne adjustment
0-255 X axle micro rotation /
0° -> 2.12°
Linearity
Explanation: CH12 each unit adjust angle 0.98°
CH12 Y axle TILT
movement
0-255 Y axle rotation / 0° -> 540° Linearity
Explanation: CH13 each unit adjust angle 0.004°
CH13 Y axle fi ne TILT
adjustment
0-255 Y axle fi ne tuning / 0° -> 540° Linearity
CH14 macro function 0-255 Unused Attribute
CH15 Reset
128-255 The complete machine reset Single step delay 5 sec.
77-127 XY axles reset Single step delay 5 sec.
26-76 Effective parts reset (color/Gobo/
lens/etc.)
Single step delay 5 sec.
0-25 Free
CH16 Bulb switch
101-255 Turn on Single step delay 5 sec.
26-100 Turn off Single step delay 5 sec.
0-25 Free
CH17 The speed of
XY axle
251-255 The fastest Linearity
1-250 Speed linear reduction Linearity
18 The fastest Linearity
