Lightmaxx Vector Shaft 7R - Device Operation and Controls; Auto and Sound Mode Operation; Connections and Control Panel Overview

DEUTSCH ENGLISH FRANCAIS ESPAÑOL
25
Connections and controls:
Operating mode Auto or Sound:
The device contains automatic programs that run according to fi xed patterns (Auto) or are recalled
via the built-in microphone to match the music (Sound). The selection of the respective mode is
made via the menu directly on the device.
DEUTSCH ENGLISH
No Description No Description
1 Display 6 DMX Output (3 pin)
2 Jogwheel 7 ON/OFF switch
3 Carrying handle 8 Fuse
4 Lense 9 Power Input (PowerCon compatible)
5 DMX Input (3 pin) 10 Power Output (PowerCon compatible)
