DEUTSCH ENGLISH
Function
LightmaXX
Vector Shaft 7R
Light sources MSD 7R
Color temperature 8000K
Effect Beam
Beam angle max. 4°
Display Ja
Power supply AC 100-240V, 50/60Hz
Power consumption 350 Watt
Power connections PowerCon compatible IN/OUT --> in total max. 4 additional Vector Shaft
7R devices can be additionally connected and supplied with power
DMX 3-pol IN/OUT
DMX mode 17 channels
Programs DMX, Auto, Sound
PAN/TILT 540°/270° (16bit)
Color wheel 14 Farben
Gobo wheel 17 Gobos
Effect wheel 8-fach Prisma, Effektbewegung, Frost
Dimmer 0-100% mechanich
Strobe Ja
Protection circuit Overheating protection, fuse
Protection class IP20
Dimensions without bracket 523 x 440 x 511 mm
Weight 19,5 Kg
Specifi cations
