Lightmaxx Vega spot 60 User Manual

DEUTSCHENGLISH
Nummer Name
Wert
9 dISP
Display Reverse
= OFF
= ON
10 rFAC
Reset Default
= OFF
= ON
11 AD t
Home Position
Delt - Clear PAN and TILT Home Position (3s)
P (PAN) = 0-120
T (TILT) = 0-120
C (COLOR) = 0-120
G (GOBO) = 0-120
F (FOCUS) = 0-120
12 rST
Reset Monitor

Lightmaxx Vega spot 60 Specifications

General

Power Consumption	90 Watt
Mains Voltage	240V, 50/60Hz
LED Source	60 Watt white LED
DMX Channels	5 channel / 15 channel
Motion	Pan = 540° / Tilt = 210°
Color Wheel	7 colours + white
Gobo Wheel	5 Gobos + open, Gobo Shake
Prism	3 facets prism
Focus	motorized
Controll Mode	DMX 512, Master/Slave, Auto Run, Sound 2 Light
Beam Angle	13°
Programs	8 internal, Sound 2 Light via DMX retrievable
Display	LED display

Weight and Dimensions

Dimensions	195 x 190 x 290 mm
Weight	4, 5 Kg
