Lightmaxx Vega spot 60 User Manual

DEUTSCH ENGLISH FRANCAIS ESPAÑOL
DEUTSCH
DEUTSCH
ENGLISH
ENGLISH
Auto or Sound mode:
The device contains automatic programs that run according to fi xed patterns (auto) or are recalled
via the built-in microphone to match the music (sound). The selection of the respective mode can be
done via the menu directly on the device.
Connections and Control Elements:
No. Description No. Description
1 LED-Lens 4 IEC Power cable Connection
2 Display 5 DMX Input (3-pol)
3 Menu keys 6 DMX Output (3-pol)
1
2
3
4
6
5

Lightmaxx Vega spot 60 Specifications

General

Power Consumption	90 Watt
Mains Voltage	240V, 50/60Hz
LED Source	60 Watt white LED
DMX Channels	5 channel / 15 channel
Motion	Pan = 540° / Tilt = 210°
Color Wheel	7 colours + white
Gobo Wheel	5 Gobos + open, Gobo Shake
Prism	3 facets prism
Focus	motorized
Controll Mode	DMX 512, Master/Slave, Auto Run, Sound 2 Light
Beam Angle	13°
Programs	8 internal, Sound 2 Light via DMX retrievable
Display	LED display

Weight and Dimensions

Dimensions	195 x 190 x 290 mm
Weight	4, 5 Kg
