Fuse(s): Value dependant on amplifier
power output
Level Control: Adjust to match
the output levels of the source unit.
Speaker Connector
Terminal: positive (+) & negative (-)
Power Connector
Terminal: power (B+), ground (GND), &
remote (REM)
Crossover Filter
Switch: full range (FULL), high-pass/sub-
sonic (HP), & low-pass/bandpass (LP)
Pass Thru Outputs:
Outputs the same signal that is fed to the inputs or
slave in/out (MD models only).
Balanced Input: Use if the
source unit has only speaker line outputs.
Adjustable Crossover
Frequency Control: 12db/Oct;
35Hz - 250Hz
Subsonic Control: Variable
subwoofer high pass filter; 15Hz - 55Hz
RCA Inputs: Line level from radio
pre-outs.
Extended Bass Control:
Bass Boost, Q-Control, Phase & Frequency Range
Output Mode Switch:
Select master or slave
LA-600M
LA-1000MD
LA-2000MD
LA-3000MD
