Lignomat Ligno-Scanner SD - Page 12

Bamboo
Item
Gypsum Sheetrock Concrete Pinless Mode
Reference Scales
RH In-Situ Concrete Pin Mode
Depth 1/4”
Depth 3/4”
Summary of all
Pinless Meters
Ligno-Scanner S S     
Ligno-Scanner D D 
Ligno-Scanner SD SD  
Ligno-Scanner SDM SDM      
Ligno-DuoTec BW BW       
Ligno-VersaTec V-0        
Summary of Pinless Meters offered by Lignomat.
SPECIFICATIONS: Ligno-Scanner S, D, SD, SDM, Ligno-DuoTec BW and Ligno-VersaTec
All pinless meters from Lignomat indicate wood moisture in percent, corrected by 71 wood group
settings or by the specifi c gravity between 0.3 to 1.0 (Settings 30 -100). Moisture Range: 5-60%.
Resolution 0.1% . HOLD function. The calibration is internally checked and adjusted before each
reading. Function and calibration can be verifi ed with the pinless test block TS. Page
Additional calibrations for
Ligno-Scanner SDM, DuoTec BW, Ligno-VersaTec:
-- Bamboo and other strand woven products
-- Sheetrock scale from 0-2%
-- Reference scales with 3 sensitivity
levels:
concrete, standard bldg materials, laminates
Size of meter: 2”x 5.5”x1/2”. Weight 8 oz.
Measuring pad 1 5/8” by 2 5/8”.
Test sample should be as large as the
measuring pads and as thick as the measur-
ing depth of the meter
.
Specifi caƟ ons are subject to change without noƟ ce.
Lignomat USA LTD, 14345 NE Morris Ct., Portland OR 97230,
503-257-8957, 800-227-2105, sales@Lignomat.com www.Lignomat.com
- Ligno-VersaTec
- Electrode E12
- Electrode E14
- RH Thermo-Hygro probe
- in-situ concrete testing
E12 E14 RH probe RH concrete
Ligno-VersaTec  Pin - Pinless- RH  All-in-one
12
