BOAT SPECIFICATIONS FOR APPROVED MOUNTING
Your LilliPad Diving Board is specifically designed for mounting on a boat with the minimum specifications as listed below.
Lillipad Diving Boards patented design is made to contain the forces generated by the jumper within its framework. However,
as with any fixture, there are some forces transmitted to the mounting surface (base). When mounted properly, very little to
no movement of the diving board will be present.
LILLIPAD DIVING BOARD MINIMUM MOUNTING SPECIFICATIONS
For mounting to a boat ONLY with the following:
Boat length – Minimum 18’
Boat Width – Minimum 7’
Floor – ¾” Marine Grade Plywood or ¾” Solid Fiberglass
Floor must be in excellent condition with no flexing, rotting, or damage of any sort present
Floor should be inspected from below the boat continuously throughout the boating season to insure it remains in
excellent condition
APPROVED DIVING BOARD POSITIONING SPECIFICATIONS
Placement of your LilliPad Diving Board is very important. As all boats move in the water from wave action and other boat
traffic, the most stable parts of the boat are recommended for installation.
APPROVED Base Position:
SIDE DOOR MOUNTING - Side Door(s) mounting provides stability from boat movement and is free of protruding
obstructions.
REAR PLATFORM / SWIM PLATFORM MOUNTING - If your boat is equipped with a platform at the stern, mount on the
Port side only.
FRONT/BOW MOUNTING – Bow mounting is permitted on vessels that DO NOT have any objects protruding from the
front of the vessel.
NOT APPROVED:
DO NOT MOUNT TO ANY BASE THAT IS NOT A BOAT WITH APPROVED SPECIFICATIONS
FRONT/BOW MOUNTING – DO NOT mount your LilliPad Diving Board on the front of your boat if any fixture
protrudes from the perimeter of the flooring surface. For example, pontoons that protrude from the front of the
vessel.
DO NOT mount your Lillipad Diving Board on ANY structure not listed in the “Approved Base Position” list above. This
includes but is not limited to docks, swim-platforms etc. Misuse of your Lillipad Diving Board could result in serious
injury and/or death.
FAILURE TO PROPERLY INSTALL THE MOUNTING SYSTEM AND/OR REMOVABLE CLEVIS PINS, EYE BOLTS, QUICK RELEASE PINS AND
BUTTON HEAD LOCK PINS CAN RESULT IN PERSONAL INJURY OR DAMAGE TO THE LILLIPAD DIVING BOARD OR YOUR BOAT.
Each mounting screw must be tightly fastened. Each eye bolt must be tightly fastened. The button head lock pin must
protrude through all cross sections with the locking balls fully exposed on the protruding side. All clevis pins must protrude
through all cross sections and be securely latched with the clevis pin key. All quick release pins must be seated with the
holding ring against the frame to which it is being inserted.
LILLIPAD DIVING BOARDS MUST ONLY BE INSTALLED USING THE FOLLOWING SPECIFICATIONS. FAILURE TO COMPLY
COULD RESULT IN DAMAGE TO THE DIVING BOARD AND/OR BOAT AND SERIOUS INJURY OR DEATH.
