7
OSD H-POSITION: to adjust the picture position in horizontal direction
OSD V-POSITION: to adjust the picture position in vertical direction
RESET: you can reset adjustment of the unit when click “YES”
COLOR TEMPERATURE：choose color and temperature at first, such as: 6500
0
K, 7500
0
K or 9300
0
K.
Only if under “USER” mode, can adjust RED, GREEN and
BLUE to meet the color value you need.
LANGUAGE：There are 2 languages provided for choice, English and Chinese
MISCELLANEOUS：to select to enter next page
As follows:
OSD MISCELLANEOUS
OSD H-POSITION ADJUSTMENT: to adjust the OSD move in horizontal
direction
OSD V-POSITION ADJUSTMENT: to adjust the OSD move in vertical
direction
OSD DURATION: to adjust the duration of OSD from5-100seconds.
OSD AUTO COLOR：If select “YES” it will adjust automatic color system to
the best.
Mode shift between 4:3 and 16:9
EXIT OSD: select “YES” to exit
To Next Page
