Limitorque SB Series User Manual

SMB/SB Installation and Maintenance Manual 140-11000 • July 2003IV
Flow Control Division
Limitorque Actuation Systems
7 SMB Disassembly & Reassembly 7-1
7.1 SMB-000 7-1
7.1.1 SMB-000 Disassembly 7-1
7.1.2 SMB-000 Reassembly 7-2
7.1.3 To Replace Stem Nut Only 7-2
7.1.4 Gasket Instructions 7-3
7.2 SMB-00 7-9
7.2.1 SMB-00 Disassembly 7-9
7.2.2 SMB-00 Reassembly 7-10
7.2.3 To Replace Stem Nut Only 7-10
7.2.4 Gasket Instructions 7-11
7.3 SMB-0, 1, 2, 3, 4, 4T 7-19
7.3.1 SMB-0, 1, 2, 3, 4, 4T Disassembly 7-19
7.3.2 SMB-0, 1, 2, 3, 4, 4T Reassembly 7-20
7.3.3 To Replace Stem Nut Only 7-21
7.3.4 Gasket Instructions 7-21
7.4 SMB-5 (Thrust and Torque) and SMB-5T (Torque Only) 7-28
7.4.1 SMB-5 and SMB-5T Disassembly 7-28
7.4.2 SMB-5 and SMB-5T Reassembly 7-30
8 SB Disassembly and Reassembly 8-1
8.1 SB-00 8-1
8.1.1 SB-00 Disassembly/Stem Nut Removal 8-1
8.1.2 SB-00 Reassembly/Stem Nut Installation 8-2
8.2 SB-0 8-5
8.2.1 SB-0 Disassembly/Stem Nut Removal 8-5
8.2.2 SB-0 Reassembly/Stem Nut Installation 8-5
8.3 SB-1 8-8
8.3.1 SB-1 Disassembly/Stem Nut Removal 8-8
8.3.2 SB-1 Reassembly/Stem Nut Installation 8-8
8.4 SB-2 8-11
8.4.1 SB-2 Disassembly/Stem Nut Removal 8-11
8.4.2 SB-2 Reassembly/Stem Nut Installation 8-12
8.5 SB-3 8-15
8.5.1 SB-3 Disassembly/Stem Nut Removal 8-15
8.5.2 SB-3 Reassembly/Stem Nut Installation 8-15
8.6 SB-4 8-18
8.6.1 SB-4 Disassembly/Stem Nut Removal 8-18
8.6.2 SB-4 Reassembly/Stem Nut Installation 8-18
9 Troubleshooting 9-1
10 How to Order Parts 10-1
11 Regulatory Information 11-1
