Lincoln DOUBLE - Bed Assembly Stage 8; Connecting Aerial and HDMI Leads; Connecting TV Power Cable

BED ASSEMBLY
Page 12 of 13
Stage
8
Aerial Lead
Aerial
Wall Socket
HDMI Leads
CONNECT CABLE
Take through the
cables from either
left or right duct.
18
18
17
AC 220V ~ 240V
!
WARNING
HAZARDOUS VOLTAGE
Contact mav cause
electric shock or burn.
This unit is to be ser
trained personnel only.
vied by
T
MODEL: LINCOLN
POWER SUPPLY: AC 220-240V~50Hz
POWER CONSUMPTION:
S/N:
20140322
TV : MAX 56W
TV LEFT : 50W
Radio: 15W
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK)
NO-USER SERVIC EABLE PARTS INSIDE REFER
SERVICING TO QUALFIED SERVICE PERSONNEL
MADE IN CHINA
POWER OUT
TO TV ONLY
POWER IN FROM
AN EARTHED WALL
SOCKET
HDMI 1 & 2
Aerial Lead
17 18
HDMI 1 & 2
Aerial Lead
17 18
Use left or right duct,
depending on the ports
that are on your TV - take
the shortest route.
TV power cable.
supplied with your TV
TV power cable
supplied with your TV
TV power cable
supplied with your TV
