Lincoln DOUBLE - Bed Assembly Stage 2 & 3; Media Tray Back Panel Assembly; Media Tray Base Panel and Support Legs

Stage
3
Bed
9
9
A
x2
Fit the support legs (9) to the underside of
the tray base panel using the bolts (A) to
secure. Fully tighten using the Allen Key (E).
Assembly
Page 7 of 13
Stage
2
7
7
6
8
5
D
x13
F
x13
Fit the barrel nuts (F), to the Media Tray back panel (7),
making sure the screw hole aligns with the intersecting
hole (see hints & tips section).
Fit the tray side panels (6
& 8
),
to the back panel (7
)
using the screws
(D) into the barrel nuts.
Fit barrel nuts (F) to the inside sides of the tray side
panels as shown.
Fit the tray base panel
(5) using the screws (D) to
secure through into the barrel nuts previously fitted.
A
A
