LINCOS STD-5335A - Page 7

LINCOS
®
AUTOMOTIVE TOOLS
7
SCISSOR VEHICLE LIFT STD-5335A
2.3. LAYOUT DIMENSION
2.4 TECHNICAL PARAMETER
1375 mm
min 220 - max 2050 mm
2030 mm
880 mm 570 mm570 mm
1375 mm
1500-1940 mm
CAPACITY 3500KG
Max. lifting height 1830mm
Platform initial height 220mm
Platform length 1500-1940mm
Platform width 570mm
Lifting time ≤50s
Descent time ≤60s
Whole machine width 2030mm
Weight 738kg
Noise ≤75dB
Installation place Indoors
Weight 762kg
Package size 1530×630×500mm
ELECTRONIC MOTOR
Type 380 V 220 V
Voltage 380V-3PH 220V-1PH
Power 2.2 KW 2.2 KW
N° Poles 50Hz 50Hz
