TECHNICAL DATA
WH25
LINDAB SAFE
11/50
TECHNICAL DATA
The sizes shown are in mm.
Dimension
Ø mm 100 125 140 150 160 180
S blade
exposition
mm 0 0 0 0 0 0
Lp mm 38 38 38 38 38 38
Ø mm 200 224 250 280 300 315
S blade
exposition
mm 0 1 0 10 20 28
Lp mm 38 38 57 57 57 57
Lp Overlap length between re damper and duct
Manual
Manual with magnet
Siemens motorized version
Belimo motorized version
Weights
Ø mm 100 125 140 150 160 180 200 224 250 280 300 315
Weight kg 2,6 2,7 2,8 2,9 3,0 3,2 3,5 4,0 4,5 5,0 5,6 5,9
Manual version. Motorized version: +1 kg
WH25
11/50
LINDAB SAFE
