ELECTRICAL CONNECTIONS
WH25
LINDAB SAFE
37/50
Voltage and power consumption -
Magnet (WH25MR/MI):
24/48 V DC (automatic voltage switching on
S0-25 electric board for 24 V magnet)
Power interrruption magnet (MR):
P = 1,6 W
Power input magnet (MI):
P = 3,4 W
Motor 24 V AC/DC (WH25VSB):
Belimo BFL24T
Opening: 2,5 W
In stand-by: 0,8 W
Motor 230 V AC (WH25DSB):
Belimo BFL230T:
Opening: 3,5 W
In stand-by: 1,1 W
Motor 24 V AC/DC (WH25VSS):
Siemens GRA126
Opening: 3,5 W
In stand-by: 2 W
Motor 230 V AC (WH25DSS):
Siemens GRA326
Opening: 4,5 W
In stand-by: 3,5 W
Microswitches position contacts
Manual control version:
12 V DC / 2 A
125 V AC / 0,1 A
Motorized version:
Siemens: AC 24 V…230 V / 6 (2) A
Belimo: DC 5 V…AC 250 V / 1 mA…3 A (0,5 A)
Blade closing time Spring: 1 s motor: < 30 s
Protection degree IP42
IP42 MAGNETIC VERSION
IP54 MOTORIZED VERSION
