Undercounter coolers
11
gure 11 a
1. Double-walled tank
2. Hose 12,7mm + insulation, input from the tank to the double-walled tank
3. Temperature probe 6m
4. Hose 12,7mm + insulation, output from the tank to the cooling device
5. Cooling device CWP 300 4x pump
15. CONNECTION DIAGRAM OF THE COOLER WITH TANK:
