Line 6 AMPLIFi FX100 User Manual

1. Bluetooth
®
Pairing Button - Using Bluetooth, your AMPLIFI FX100
will communicate wirelessly with your iOS device. Before you run the
AMPLIFi Remote app, set up Bluetooth as follows:
To pair your amp with your iOS device:
• Enter Pairing Mode on the AMPLIFi FX100 by pressing the
Bluetoothbuttononthetoppanelofthepedal-itwillash.
• Enter Bluetooth Pairing mode on your iOS device.
• Your amp's unique name will appear on your iOS device.
• Select your amp's unique name on your iOS device - this pairs it
up with your device!
2. Tone Controls - When using AMPLIFi Remote with your iOS device,
all Tone adjustments can be made using the app Editor. You can also
tweak your guitar sound manually with these onboard Tone controls:
DRIVE: Adjusts the current Amp Model's Drive level.
BASS, MID, TREBLE: Adjusts the Bass, Mid and Treble levels for
the current Amp Model's tone stack.
FX: Adjusts the FX parameter assigned to the Tweak Knob as part of
the preset. This assignment can be edited in the AMPLIFi Remote
application.
REVERB: Adjusts the Reverb level for the current Guitar Preset.
3. Master Volume Knob - This big knob controls the overall output
level of your AMPLIFi FX100. It also has a Secondary Function of
adjusting your guitar level relative to the overall audio mix. This can
be useful when you're jamming to a track and your guitar level is too
soft or too loud.
To achieve a good balance, simply press the Master Volume knob to
activate its Secondary Function, then set your guitar level as desired.
After 5 seconds, the knob reverts to Master Volume control.
Master Volume LED RIng
Master Volume LED Ring - The ring of LEDs surrounding the Master
Volume knob light up in various ways, depending on the current
parameter being adjusted, as follows:
• Master Volume: LEDs are lit red to indicate Master Volume level.
• Guitar Level: Press the Master Volume Knob to adjust guitar level.
White LEDs indicate the current level of the guitar.
• Tone Controls: When an individual Tone Control is adjusted, the
saved level is indicated by a single red LED: all other LEDs are lit
white to display the current level as you turn the knob.
4. Preset Select Footswitches - 4 Presets are stored within each
Preset Bank in the AMPLIFi FX100 internal memory: Presets A, B,
CandD.APresetstoresalloftheampandeectsparametersthat
denethecharacteristicsofthetone.
To Load A Preset: Press one of the four Preset Select Footswitches
(A - D) to load the Preset associated with the footswitch. The red LED
around the footswitch will indicate your current selection.
To Save A Preset: Press and hold the footswitch that indicates
your current selection to enter save mode. Footswitches A-D will
beginashing;thenextfootswitchpresswillsavethepresettothat
location. Note that you able to save presets to any bank while in
save mode. (See bank changing instructions below)
