Rear Panel Connections
8. Guitar Input - Plug in your 1/4 inch guitar cable here.
9. Headphones - Plug in your 1/4 inch stereo headphones cable here.
Headphones volume is controlled by the Master Volume knob.
10. Main Outs - The Main Outs provide full range audio, sending out
a mix of processed guitar and any Bluetooth audio that may be
streaming to the unit. Plug 1/4 inch cables to the Main Outs to
connect to any number of destinations, such as a mixing console,
PA speakers or home stereo (using appropriate 1/4 inch adapters).
11. Amp Out - The Amp Out provides a 1/4 inch mono output of guitar
processedwith amp modeling and eects. Bluetooth audio is not
sent to the Amp Out.
Using Main Outs & Amp Out Together - Only Bluetooth audio will
be present at the Main Outs when the Amp Out jack is connected.
12. USB Port - For future use.
13. Power Supply Input - Only use a Line 6 9VDC Power Supply here to
power the unit.
14. Power - Switch on the power with this rocker switch, located just
above the AC cable receptacle.
AMPLIFi Remote Application For iOS
Download the latest version of the free AMPLIFi Remote iOS application
in the App Store
SM
.
And while you're online, don't forget to register your AMPLIFi FX100!
AMPLIFi Firmware Updates
Alwaysrunthe latestrmwareinyour AMPLIFi FX100. Your AMPLIFi
Remote application will inform you whenever a rmware update is
available, so you'll always know you have the latest version!
8 910 11 12 13 14
