Line 6 Mechanical Engineering
FloorJam F8-1 Complete
Unit
Assembly Instructions Rev B
Document # L6D000184
Confidential
Page 10 of 22
5/23/2008
STEP 7 continued
Correct LIGHT PIPE a
nd BEZEL orientation.
Part clips into slots as shown.
35
37
Table of Contents
M13 Stompbox Modeler
1
Main PCBA Schematic
2
UI PCBA Schematic
10
Main PCBA Assembly Instructions
14
UI PCBA Assembly Instructions
20
FLOOR JAM USER INTERFACE_BREAKAWAY PCBA
20
ASSEMBLY INSTRUCTIONS
20
B - Instruction updated to include Ribbon Cable Assemblies. 03/27/2008 ANTHONY PASCUZZO
25
Final Assembly Instructions
27
JM4 Parts List
49
