03/27/08 Page 1 of 7
LINE 6 CONFIDENTIAL
FLOOR JAM USER INTERFACE_BREAKAWAY PCBA
ASSEMBLY INSTRUCTIONS
Rev. B
USER INTERFACE UPPER PCBA: (50-02-0272)
Refers to User Interface Upper PCB Rev. A: (35-00-0272)
USER INTERFACE MIDDLE PCBA: (50-02-0272-1)
Refers to User Interface Middle PCB Rev. A: (35-00-0272-1)
USER INTERFACE LOWER PCBA: (50-02-0272-2)
Refers to User Interface Lower PCB Rev. A PCB: (35-00-0272-2)
