59-00-0331 ASSY UNIT COMPLETE FLOOR JAM F8-1
PART NUMBER DESCRIPTION QTY REFERENCE DESIGNATOR(S)
30-51-0295 CLIP E STYLE FOR 7/32" DIA SHAFT STEEL BLACK PHOS P11-1 4
30-51-0326 BOTTOM PLATE METAL 12.2 x 7 x .031" F8 1
41-00-0174 ARTWORK SILKSCREEN BOTTOM FLOOR JAM F8-1 1
30-51-0327 OVERLAY TOP 10.4 x 1.6 x .025 ALUMINUM F8 1
41-00-0171 ARTWORK SILKSCREEN OVERLAY TOP FLOOR JAM F8-1 1
30-51-0328 OVERLAY REAR 11.5 x 1.9 x .03 ALUMINUM F8 1
41-00-0172 ARTWORK SILKSCREEN OVERLAY BACK PANEL FLOOR JAM F8-1 1
30-51-4007 CHASSIS TOP COVER 320 x 186 x 64 ALUMINUM TITANIUM F8-1 1
41-00-0173 ARTWORK SILKSCREEN CHASSIS FLOOR JAM F8-1 1
30-60-0006 LOGO LINE 6 SML 38.35 x 7.98MM w/ADHSV BRUSHED/BLK FINISH AL 1
30-63-0028 FOAM RING 4-WAY SW RET PU .75 OD x .40 ID x .18 HT BLK 1
30-63-0041 FOAM EVE BLACK w/ADHSV 1 SIDE 57mm x 32mm x 2mm 1
50-02-0271 PCBA MAIN FLOOR JAM F8 1
50-02-0272 PCBA UI UPPER FLOOR JAM F8 1
50-02-0271 PCBA MAIN FLOOR JAM F8
PART NUMBER DESCRIPTION QTY REFERENCE DESIGNATOR(S)
01-22-0101 RES METAL OXIDE 100R 2W 5% TH 2 R144, R145
01-22-0330 RES METAL OXIDE 33R 2W 5% TH 2 R142, R143
01-24-0000 RES 0R 1% 0805 2 R24,R60
01-24-1001 RES 1.00K 1% 0805 10 R3, R4,R42, R43,R69,R80,R82,R86,R89,R101
01-24-1002 RES 10.0K 1% 0805 9 R47,R49,R53,R56, R57,R59,R136,R138,R141
01-24-1003 RES 100K 1% 0805 3 R50, R51,R113
01-24-1004 RES 1.00M 1% 0805 5 R6,R41,R54,R58,R64
01-24-1071 RES 1.07K 1% 0805 1 R105
01-24-10R0 RES 10.0R 1% 0805 1 R93
01-24-1500 RES 150R 1% 0805 13 R10,R12,R15,R20,R25, R26,R28, R29, R30,R32, R33,R35,R38
01-24-1502 RES 15.0K 1% 0805 3 R2,R22,R27
01-24-1620 RES 162R 1% 0805 1 R81
01-24-1871 RES 1.87K 1% 0805 1 R103
01-24-2001 RES 2.00K 1% 0805 15 R39, R40,R62, R63,R67, R68,R72,R83, R84,R87, R88,R91, R92,R96, R97
01-24-2002 RES 20.0K 1% 0805 6 R52,R55,R118,R121,R126, R127
01-24-2211 RES 2.21K 1% 0805 1 R140
01-24-22R1 RES 22.1R 1% 0805 6 R1,R5,R7,R31,R34,R48
01-24-28R7 RES 28.7R 1% 0805 1 R85
01-24-30R1 RES 30.1R 1% 0805 3 R11,R19,R70
01-24-3161 RES 3.16K 1% 0805 2 R9,R23
01-24-4751 RES 4.75K 1% 0805 10 R13, R14,R17, R18,R36, R37,R44,R46,R107, R108
01-24-4752 RES 47.5K 1% 0805 6 R16,R21,R109, R110, R111, R112
01-24-47R5 RES 47.5R 1% 0805 9 R65,R73,R76,R115, R116,R122 R123, R124,R128
01-24-5R11 RES 5.11R 1% 0805 1 R114
01-24-6811 RES 6.81K 1% 0805 6 R61,R66,R98,R134, R135,R139
01-24-8251 RES 8.25K 1% 0805 1 R137
01-25-1002 RES 10.0K 1% 0603 1 R132
