50-02-0271 PCBA MAIN FLOOR JAM F8
PART NUMBER DESCRIPTION QTY REFERENCE DESIGNATOR(S)
01-25-4751 RES 4.75K 1% 0603 20
R75,R77, R78, R79,R90,R94, R95,R99, R100,R102,R104,R129, R130, R131,R133,R106R119,
R106R120,R45 R71
01-48-9208 POT SINGLE 10KC SINGLE LOG RIGHT ANGLE 15MM NYLON D-SHAFT 1 R74
01-48-9209 POT SINGLE 10K05C SINGLE LOG RIGHT ANGLE 15MM NYLON D-SHAFT 1 R8
03-11-0108 CAP ELEC 1000uF 10V 20% 105C LOW Z 0.06R RADIAL 10/20/5 1 C177
03-00-2105 CAP CER 1uF 25V X7R 10% TH 5mm L.S. 1
03-00-4102 CAP CER 1nF 50V X7R 20% TH RADIAL 5.0mm L.S. 1
03-00-4471 CAP CER 470pF 50V 10% TH RADIAL 5.0mm L.S. 1
03-12-0108 CAP ELEC 1000uF 16V 20% RADIAL 10/16/5 2 C65, C66
03-12-0478 CAP ELEC 4700uF 16V 20% RADIAL 1 C70
03-13-0477 CAP ELEC 470uF 16V 20% 105C LOW Z 0.085R RADIAL 8/15/5 1 C178
03-16-2108 CAP ELEC 1000uF 35V 20% 105C LOW Z RADIAL 12.5/25/5 3 C60,C63,C71
03-36-0224 CAP ESTR 0.22uF 50V 5% TH 11/6/11.5/7.5 1 C67
03-50-0101 CAP NPO 100pF 50V 5% 0805 3 C111,C165,C175
03-50-0102 CAP NPO 1nF 50V 5% 0805 3 C43,C131,C137
03-50-0220 CAP NPO 22pF 50V 5% 0805 4 C106, C107,C152,C160
03-50-0272 CAP NPO 2.7nF 50V 5% 0805 9 C9,C12,C15, C16,C19,C22,C39,C161,C173
03-50-0391 CAP NPO 390pF 50V 5% 0805 1 C58
03-50-0470 CAP NPO 47pF 50V 5% 0805 8 C31,C73, C74,C85,C90,C98,C100,C102
03-50-0471 CAP NPO 470pF 50V 5% 0805 6 C36,C38,C53,C55,C167,C174
03-52-0101 CAP X7R 100pF 50V 10% 0805 7 C72,C97,C101,C112,C141,C162,C176
03-52-0103 CAP X7R 10nF 50V 10% 0805 1 C180
03-52-0104 CAP X7R 0.1uF 50V 10% 0805 17 C29,C51, C52,C56,C64,C68-C69,C76,C83, C84,C86,C88,C91, C92, C93,C1 C24
03-52-0180 CAP X7R 18pF 50V 10% 0805 2 C49, C50
03-52-0220 CAP X7R 22pF 50V 10% 0805 1 C40
03-52-0473 CAP X7R 47nF 50V 10% 0805 5 C21,C23,C96,C99,C181
03-52-0561 CAP X7R 560pF 50V 10% 0805 1 C194
03-56-0101 CAP NPO 100pF 50V 5% 0603 2 C2,C182
03-58-0102 CAP X7R 1nF 50V 10% 0603 21
C48,C62,C87,C89,C94,C109,C113,C115,C119,C122,C125,C130,C133, C134,
C135,C139,C143,C146,C149,C151,C154
03-58-0104 CAP X7R 0.1uF 25V 10% 0603 43
C27,C30,C32,C35,C37,C46-C47,C54,C57,C59,C61,C79-C80,C104, C105,C117,
C118,C120,C121,C123,C124,C126,C127,C129,C138,C140,C144,C145,C147,C148,C150,C153
,C155,C156,C159,C163,C164,C166,C169,C170,C172,C132C136
03-58-0330 CAP X7R 33pF 50V 10% 0603 10 C41,C42,C44,C45,C103,C108,C110,C114,C116,C128
03-58-0470 CAP X7R 47pF 50V 10% 0603 2 C184,C185
03-80-0107 CAP ELEC 100uF 10V 20% SM 6.3/5.4/7.8 3 C17,C82,C171
03-80-0337 CAP ELEC 330uF 10V 20% VS SM 1 C8
03-80-1477 CAP ELEC 470uF 6.3V 20% VS SM 2 C75,C157
03-82-0107 CAP ELEC 100uF 16V 20% VS SM 6 C3-C5,C14,C26,C28
03-84-0106 CAP ELEC 10uF 25V 20% SM 5/5.4/6.5 5 C77,C78,C81,C168,C179
03-88-0105 CAP ELEC 1uF 50V 20% VS SM 6 C6,C10,C13,C20,C25
03-88-0106 CAP ELEC 10uF 50V 20% VS SM 5 C7,C11,C33,C34,C197
04-01-0150 INDUCTOR POWER 150uH 0.25 OHM 1 L33
