50-02-0271 PCBA MAIN FLOOR JAM F8
PART NUMBER DESCRIPTION QTY REFERENCE DESIGNATOR(S)
06-20-0099 DIODE GEN PUR DUAL 70V 215mA 6nS SOT-23 SM 5 D8,D9,D20,D21,D22
06-23-0054 DIODE SCHOTTKY DUAL 30V 200mA 5nS SOT-23 SM 4 D1,D2,D6,D7
06-23-0340 DIODE SCHOTTKY 3A 40V SMA SM 1 D10
06-32-0130 DIODE SCHOTTKY 1A 30V SMB SM 1 D12
06-32-0313 DIODE RECTIFIER 200V 3A SMB SM 2 D18,D19
06-32-4006 DIODE RECTIFIER 800V 1A SMA SM 4 D14.D15,D16,D17
09-10-4403 TRANS PNP SMALL SIGNAL SOT-23 SM 1 Q1
11-00-1001 CRYSTAL 10MHz 2 PIN HC-49US TH 1 Y2
11-00-1002 CRYSTAL 22.5792MHz 2 PIN TH 1 Y1
11-10-2012 FERRITE BEAD 600R @ 100MHz 300 mA 0805 SM 30
L1,L2,L3,L6,L7,L8,L9,L10,L11,L12,L13,L14,L15,L16,L17,L18,L19,L20,L21,L22,L23,L24L24,L25,
L26,L27,L28,L29,L30,L31,L32
12-00-0317 IC VREG ADJ 1.2V-37V 1.5 AMP TO-220 LM317 TH 1 U22
12-02-7805 IC REG +5V 1.5 AMP TH 2 U21,U23
12-02-7812 IC REG +12V 1.0AMP TO -220 TH 1 U19
12-02-7912 IC REG -12V 1.0AMP TO-220 TH 1 U20
12-52-1118 IC REG 1.8V LDO LINEAR 800mA S OT-223 SM 1 U17
12-54-0082 IC OP AMP DUAL TL082CD SO-8 SM 3 U1,U8,U16
12-54-0084 IC OP AMP QUAD TL084CD SM 4 U3,U5,U11,U13
12-54-4560 IC OP AMP DUAL HIGH OUTPUT NJM4560M DMP8 DUAL SUPPLY SM 1 U2
12-64-4243 IC CODEC TDM 108dB 192KHz 6- IN 6-OUT CS42436 SM 1 U4
15-65-0004 IC 74LVC04 LOW VOLTAGE HEX INV ERTER SO-14 SM 1 U6
15-68-2374 IC PWM DC/DC CONVERTER DMP8 SM 1 U18
15-70-0005 IC SDRAM 3.3V 64MB 1M x 16 x 4 EM638165TS-7G TSOP-54 SM 2 U9,U12
15-78-5128 IC FLASH 512M x 8 BIT TSOP-48 SM 1 U7
15-86-1371 IC DSP SHARC PROCESSOR ADSP-21 371 1 U10
15-92-5809 IC RESET 3 PIN 3.3V ACTIVE LOW OUTPUT SOT-23 SM 1 U14
21-00-0014 JACK BARREL PCB MT 2.5MM DC PO WER 3 PIN TH 1 J9
21-00-6616 JACK 1/4" TRS PCB MOUNT 6 PIN HORIZONTAL TH 5 J1,J3,J4,J5,J6
21-08-0002 JACK XLR FEMALE PCB MOUNT RT ANGLE W/NO RELEASE TAB TH 1 J2
21-12-0035 JACK 3.5MM STEREO 5 PIN CRIMPE D LEADS NON-THREADED 2 J7,J8
21-18-0900 CONN SD MEMORY CARD SOCKET PCB MNT SM 1 J10
21-21-0040 HDR DIL PCB-MT 40 PIN 2 x 20 x .100 MALE SHRD VERT MNT TH 1 H1
30-12-0012 STANDOFF HEX .250 6-32 F-F 0.375-IN AL 5
30-15-0007 INSULATOR XTAL 4.9MM C-C 11.8 x 5.6MM MYLAR 2 Y1,Y2
30-18-3030 CLIP GROUND PCB .30 x .30 x .0 7 7 GF1,GF2,GF3,GF4,GF5,GF6,GF7
30-51-0146 SHIELD PCB MT FOR 1/4 JACK 1.00 Hx1.25Wx.013THK BERYL COP 2 SH1,SH2
35-00-0271 PCB MAIN FLOOR JAM F8-1 REV.D 1
45-01-0040 IC PROGRAMMED MCU v2.07 FLOOR JAM F8-1 1 U15
