50-02-0272 PCBA UI UPPER FLOOR JAM F8
PART NUMBER DESCRIPTION QTY REFERENCE DESIGNATOR(S)
01-24-1001 RES 1.00K 1% 0805 4 R5,R14,R15,R27
01-24-1300 RES 130R 1% 0805 3 R7,R8,R17
01-24-1500 RES 150R 1% 0805 1 R24
01-24-18R7 RES 18.7R 1% 0805 2 R2,R3
01-24-2000 RES 200R 1% 0805 1 R25
01-24-26R7 RES 26.7R 1% 0805 1 R1
01-24-3010 RES 301R 1% 0805 1 R16
01-24-4321 RES 4.32K 1% 0805 1 R4
01-24-4751 RES 4.75K 1% 0805 3 R12,R13,R26
01-24-7500 RES 750R 1% 0805 4 R20,R21,R22,R23
01-24-7501 RES 7.50K 1% 0805 1 R6
01-25-4751 RES 4.75K 1% 0603 5 R9,R10,R11,R18,R19
03-52-0101 CAP X7R 100pF 50V 10% 0805 8 C1,C2,C4,C5,C9,C13,C18,C19
03-58-0104 CAP X7R 0.1uF 25V 10% 0603 3 C6,C8,C12
03-80-1477 CAP ELEC 470uF 6.3V 20% VS SM 1 C3
03-82-0106 CAP ELEC 10uF 16V 20% SM 4/5.4/5.5 1 C7
06-34-0016 DIODE SWITCHING 75V 200mA 6nS SOT-23 SM 10 D5,D8,D11,D14,D15,D16,D17,D19,D20,D21
09-10-4401 TRANS NPN SMALL SIGNAL SOT-23 SM 6 Q1,Q2,Q5,Q6,Q7,Q8
09-10-4403 TRANS PNP SMALL SIGNAL SOT-23 SM 3 Q3,Q4,Q9
15-64-0273 IC 74HCT273 OCTAL D-TYPE FLIP FLOP 8 BIT SO-20 SM 2 U1,U2
18-00-0314 LED RED DIFFUSED TH 1 D18
18-20-0002 LED RED SUPER 2MM x 1.25MM 660 nM 0805 SM 2 D1,D2
18-22-0003 LED YELLOW SUPER BRIGHT 2MM x 1.25MM SM 12 D3,D4,D6,D7,D9,D10,D12,D13,D22,D23,D24,D25
21-30-0052 CBL RIBBON DIL 40 PIN 95.2 MM STAKED TO FEMALE CONN (F8) 1 H1
24-12-0111 ENCODER 20 STEP TH 1 E1
24-31-1105 SWITCH TACT 6MM SQ 4 PIN TH 10 SW1,SW2,SW3,SW4,SW8,SW9,SW10,SW12,SW13
30-15-0029-3 SPACER LED .590 H x .170 O.D. PLASTIC 1
35-00-0272 PCB UI UPPER FLOOR JAM F8-1 REV.D 1
50-02-0240 PCBA DISPLAY LCD GRAPHIC W/20P MALE HDR 6-O'CLOCK XMIS POS 1
50-02-0240 PCBA DISPLAY LCD GRAPHIC W/20P MALE HDR 6-O'CLOCK XMIS POS
PART NUMBER DESCRIPTION QTY REFERENCE DESIGNATOR(S)
21-20-0022 HDR SIL PCB-MT 20 PIN 1 x 20 x .10 MALE VERT MNT X-LG TH 1
18-30-0006 DISPLAY LCD MODULE 122x32 POS GRAPHIC 6-O'CLOCK XMISSVE AMBR 1
