Backup/Restore to/from Local PC
Backup
Configuration
Once you have the access point working properly, you
should back up the settings to a file on your computer.
You can later restore the access point's settings from
this file, if necessary.
To create a backup file of the current settings:
Click Backup.
If you don't have your browser set up to save
downloaded files automatically, locate where
you want to save the file, rename it if you like,
and click Save.
Restore
Configuration
To restore settings from a backup file:
1.
Click Choose File.
2.
Locate and select the previously saved backup
file.
3.
Click Restore.
Backup/Restore to/from TFTP server
Backup
Configuration
To create a backup file of the current settings:
1.
Enter the destination file name you plan to save
in TFTP server.
2.
Enter the IP address for the TFTP server. Only
IPv4 addresses are supported.
3.
Click Backup.
Restore
Configuration
To restore settings from a backup file:
1.
Enter the source file name stored in TFTP
server.
2.
Enter the IP address for the TFTP server. Only
IPv4 addresses are supported.
3.
Click Restore.
91

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Linksys AC1200 and is the answer not in the manual?

Linksys AC1200 Specifications

General IconGeneral
Maximum Data Rate1200 Mbps
Security FeaturesWPA2, WPA, WEP
Wireless Standard802.11ac
Frequency Bands2.4 GHz, 5 GHz
Wireless Speed867 Mbps (5 GHz) + 300 Mbps (2.4 GHz)
Operating Temperature0°C to 40°C (32 to 104°F)
Storage Temperature-4°F to 158°F (-20°C to 70°C)
Operating Humidity10% to 85% (non-condensing)
Storage Humidity5% to 90% (non-condensing)
