Linksys E2000 Configuration Guide

Revision 1.1 Page 19
®®
Appendix A- Client/Server Architecture
The N2KView
®
Vessel Monitoring and Control System is based on a client/server architecture.
In this context, a server is defined as a component that provides services over a network and a
client is defined as a station that requests and uses those services.
Within the N2KView
®
System, there is generally one server (called N2KServer
®
) and one or
more stations or clients (called N2KView
®
). The server component is implemented by either an
IPG100 or N2KServer
®
software running on a Windows PC, and the station or client
components are implemented by the N2KView
®
software. N2KView
®
software may run on a
Windows PC, Mac, or Maretron
®
’s MBB100 or DSM800. Mobile versions of N2KView
®
software are available for iPod Touch, iPhone, iPad and most Android devices. The service
offered by the server to the stations (clients) is access to the NMEA 2000
®
network data that
the server receives from the NMEA 2000
®
network via its NMEA 2000
®
gateway. The network
over which this service is offered is implemented as a TCP/IP (Transmission Control
Protocol/Internet Protocol) network, which is discussed in the next section.

Linksys E2000 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Input current	1 A
Input voltage	12 V
Dimensions (WxDxH)	202 x 34 x 160 mm
WLAN data transfer rates supported	300 Mbit/s
DHCP client	-
Antennas quantity	3
Antenna gain level (max)	2.2 dBi
Web-based management	No
Security algorithms	WEP, WPA, WPA2
Certification	FCC, CE, IC-03, Wi-Fi
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	300 g
